Product family
Oil Resistant Belts
DIN-G covers for oily duty.
Oil resistant covers that hold their grip and shape against mineral and vegetable oils. Oil seeds, timber, soap and chemical plants.
The covers in this family
What each cover is made to achieve, against the standard.
Oil resistant
Mineral and vegetable oils, greases and solvents.
- Covers that resist swelling in mineral and vegetable oils
- Keeps grip and shape on oily seeds, meal and wood chips
- For oil mills, soap, timber and chemical plants
- Built to IS 1891 Part 4 and DIN-G
Conveyor positions we supply with this family
Every rating and ply count we build
Each cell is a carcass. The number is how many cover and grade options it comes in. Click to open them in the catalogue.
| kN/m | 2 ply | 3 ply | 4 ply | 5 ply | 6 ply |
|---|---|---|---|---|---|
| EP 200 | 8 | ||||
| EP 250 | 8 | 8 | |||
| EP 315 | 8 | 8 | |||
| EP 400 | 16 | 16 | |||
| EP 500 | 16 | 16 | |||
| EP 630 | 16 | 16 | |||
| EP 800 | 16 | 16 | |||
| EP 1000 | 16 | 16 | |||
| EP 1250 | 16 | 16 |
Thickness across the range
From the thinnest to the thickest cover option at each rating, mm
Cover pairs: 1.5+1.5 · 2+1 · 3+1.5 · 4+2 · 5+2 · 6+2 · 6+3 · 8+2 · 8+3 · 10+3 mm
Where most buyers start
Need oil resistant belts?
Tell us the material, width and length. A written quotation with a certified datasheet usually goes out the same day.
