Product family
Fire Resistant Belts
FR antistatic to ISO 340.
Flame resistant, antistatic belting for power plants, coal handling and enclosed conveyors where safety codes demand it.
The covers in this family
What each cover is made to achieve, against the standard.
Fire resistant antistatic
Flame resistance to ISO 340 with antistatic covers.
- Self-extinguishing covers, flame tested to ISO 340
- Antistatic, so no spark builds up on the belt
- For coal handling plants, power stations and closed galleries
- Built to IS 1891 Part 5, accepted where safety codes demand it
Flame tested to ISO 340, antistatic covers
See these belts →
Conveyor positions we supply with this family
Every rating and ply count we build
Each cell is a carcass. The number is how many cover and grade options it comes in. Click to open them in the catalogue.
| kN/m | 2 ply | 3 ply | 4 ply | 5 ply | 6 ply |
|---|---|---|---|---|---|
| EP 200 | 4 | ||||
| EP 250 | 4 | 4 | |||
| EP 315 | 4 | 4 | |||
| EP 400 | 14 | 14 | |||
| EP 500 | 14 | 14 | |||
| EP 630 | 14 | 14 | |||
| EP 800 | 16 | 16 | |||
| EP 1000 | 16 | 16 | |||
| EP 1250 | 16 | 16 |
Thickness across the range
From the thinnest to the thickest cover option at each rating, mm
Cover pairs: 3+1.5 · 4+2 · 5+2 · 6+2 · 6+3 · 8+2 · 8+3 · 10+3 mm
Where most buyers start
Need fire resistant belts?
Tell us the material, width and length. A written quotation with a certified datasheet usually goes out the same day.
Guides
Read before you order
Fire resistant conveyor belts
What makes a conveyor belt fire resistant and antistatic, the ISO 340 flame test, where FR belts are required (coal handling, power plants, underground) and how to specify them under IS 1891 Part 5.
Read the guide →
Conveyor belts for power plants and coal handling
Conveyor belts for coal handling plants and power stations: fire resistant antistatic FR belts to ISO 340, belts for fly ash, lignite and biomass, and how to specify them.
Read the guide →
Conveyor belt cover grades explained
M24 vs N17, DIN X vs Y vs W, heat T1 T2 T3, oil, fire and food grade conveyor belt covers compared: tensile strength, elongation, abrasion loss and temperature limits under IS 1891 and DIN 22102.
Read the guide →
